Economical Bacterial Crushing Ultrasonic Homogenizer

Product Description

Features :

Using microcontroller technology+4.3-inch TFT capacitive touch screen control

Central microcomputer centralized control, ultrasound time, power can be set from 1% to 100%

Sample temperature detection display, frequency microcomputer automatic tracking, automatic fault alarm

A set of matching Alcoa 7075 transducer and high-purity titanium alloy amplitude rod

Equipped with overload protection function

The standard amplitude lever is 6mm

It can achieve voice alarm function caused by faults, overheating, or operational errors

The difference between JY Series economical ultrasonic homogenizer and HX Intelligent ultrasonic homogenizer

1:JY Series sonicator host and soundproof box detached,while HX Series one can put host and soundproof box in stack

2:JY Series with 4.3inch screen ,while HX Series with 7inches LCD screen

3: JY Series lifting platform is manual type; HX Series lifting platform is eletrical type

4 HX Series with Light and Sterilization function while JY Series models do not have such function.

5 HX Series with better horns which with better quality polished materials

The specifications

Model	JY96-IIN	JY88-IIN	JY92-IIN	JY92-IIDN
Power	1.5~150W Continuous	2.5~200W Continuous	10~650W Continuous	10~900W Continuous
Capacity	0.1~150ml	0.1~300ml	0.1~500ml	0.1~600ml
Standard horn	6mm	6mm	6mm	6mm
Optional horns	2/3/8/10mm	2/3/8/10mm	2/3/8/10/12mm	2/3/8/10/12/15mm
Ultrasonic set time	0.1~99.9s
Ultrasonic stop time	0.1~99.9s
Total time	1~99h59min59s
Frequency range	20~25Khz
Temperature control range	0~100(optional low temperature thermostat)
Alarm function	Time,overload,no load,over temperature
Data storage	20sets
Power Supply	220V/110V/50Hz/60Hz
Other functions	Voice alarm and prompt function

Model	HX-IID	JY98-IIIDN	JY99-IIDN
Power	10~1000W	20~1200W	50~1800W
Capacity	0.1~750ml	1~1000ml	1~1200ml
Standard horn	6mm	20mm	22mm
Optional horns	2/3/8/10/12/15	3/6/8/10/15/22/25	8/10/15/20/25mm
Ultrasonic set time	0.1~99.9s
Ultrasonic stop time	0.1~99.9s
Total time	1~99h59min59s
Frequency range	20~25Khz
Temperature control range	0~100(optional low temperature thermostat)
Alarm function	Time,overload,no load,over temperature
Data storage	20sets
Power Supply	220V/110V/50Hz/60Hz
Other functions	Voice alarm and prompt function
Power	0.1~99.9s

Horns Specifications
