Description
This Handheld Ultrasonic probe sonicator was a compact and cost effective ultrasonic processor on the market and features large LCD display and optional soundproof enclosure. Probes or horns are made from titanium to specific sizes and shapes. The standard horn size is Φ5 mm.
Features
● Probe and host integrated design, high efficiency, energy saving, portable
● Ultrasound can be controlled manually or with clamps which is especially suitable for micro or small amount of sample processing;
● The variable amplitude rod is made of titanium alloy material, with high strength, high sound velocity, good corrosion resistance and high heat resistance
The Technical Parameters
Model | HX-250 | HX-400 |
Power | 2.5~250W Continuous | 4~400W Continuous |
Crushing capacity | 0.1~150ml(with optional horns) | 0.1~300ml(with optional horns) |
Standard horn | 5mm | 5mm |
Optional horns | 2/3/6mm | 2/3/6mm |
Single ultrasound time | 0.1~99.9s | |
Single ultrasound stop time | 0.1~99.9s | |
Total time | 0~99h59min59s | |
Frequency | 20-30Khz | |
Temperature control range | 0~100(optional low temperature thermostat) | |
Alarm function | Time,overload ,no load, over temperature | |
Display mode | 20sets | |
Power Supply | 220V/110V/50Hz/60Hz | |
Sonicator host material | ABS molded in whole one , can support the upper and lower stacking | |
Voice alarm and prompt function | standard | |
Optional function | Computer communication and data printing | |
Size | 427*340*168mm | |
