Made of high quality stainless steel, superior corrosion resistance, acid and alkali resistance, solids and liquids, liquids and liquids mixed to form solutions, colloids, suspensions or emulsions can be used。the rotating speed up to 31,000 rpm, quickly and evenly disperse powder and liquid material intothe liquid. Widely used in cosmetics, creams, oil and water emulsification, tissue crushing, biopharmaceuticals, pesticides, fine chemicals and other fields.
Technical Parameters
| Model | HR-500 | HR-500D |
| Item No | 1004010000 | 1004011000 |
| Type | Basic | Digital |
| Voltage(V) | 220 | 220 |
| Power(W) | 500 | 500 |
| Frequency(Hz) | 50~60 | 50~60 |
| Speed Range(rpm) | 10000~31000 | 10000~31000 |
| Speed Display | Scale display | LED |
| Speed Adjust Mode | Stepless | Stepless |
| Capacity(ml) | 0.2~7000ml | 0.2~7000ml |
| Standard Working Head | HR25P-25G-S2V | HR25P-25G-S2V |
| Head Material | SS316 | SS316 |
| Shaft Sleeve Material | PTFE | PTFE |
| Applicable temperature(C°) | ≤120 | ≤120 |
| Allowable Ambient Temperature(C°) | 5~40 | 5~40 |
| Allowable Ambient Humidity(%) | 80 | 80 |
| Host Packing Size(mm) | 470*340*205 | 470*335*200 |
| Host NW | 3 | 3 |
| Host GW | 3.7 | 4 |
Speed Parameter (idle condition)
HR-500 Reference Speed
| Gear | 1 | 2 | 3 | 4 | 5 | 6 |
| Speed rpm(reference value） | 10000 | 15000 | 20000 | 24000 | 28000 | 31000 |
