Product Features:
Aluminium die-cast ceramic coated working discs with superior resistance to wear, corrosion, high temperature and oxidation;
Wide temperature control range, HMS-206 series can up to 350 ℃,HMS-208 series can up to 400 ℃, heating function is individually controlled, and the button highlights after the heating is turned on, which is convenient for operation;
LCD backlight design, real-time display of temperature and speed, easy to observe;
Dual heating control circuits, knobs with run-lock anti-misoperation function
Technical Parameters:
| Model | HMS-206 | HMS-206D | HMS-208 | HMS-208D |
| Item No | 1002042005 | 1002043005 | 1002021005 | 1002022005 |
| Voltage(V) | 220 | 220 | 220 | 220 |
| Frequency(Hz) | 50~60 | 50~60 | 50~60 | 50~60 |
| Time Setting Range | - | 0~99h59min | - | 0~99h59min |
| Motor Type | DC Brushless Motor | DC Brushless Motor | DC Brushless Motor | DC Brushless Motor |
| Display Mode | Scale | LCD | Scale | LCD |
| Whole Machine Power(W) | 600 | 600 | 900 | 900 |
| Motor Output Power(W) | 15 | 15 | 15 | 15 |
| Heating Output Power(W) | 550 | 550 | 850 | 850 |
| Speed Range(rpm) | 0-2000 | 100-2000 | 0-2000 | 100-2000 |
| Max Capacity(L) | 20 | 20 | 20 | 20 |
| Heating Plate Size(mm) | 145 | 145 | 145 | 145 |
| Working Plate Material | Aluminum die-cast ceramic coating | |||
| Heating Mode | Heating tube | Heating tube | Heating tube | Heating tube |
| Temperature Range | RT+5~350℃ | RT+5~350℃ | RT+5~400℃ | RT+5~400℃ |
| Temperature Resolution | - | 0.1 | - | 0.1 |
| Over temperature protection (℃) | ≤420 | ≤420 | ≤450 | ≤450 |
| Temperature Sensor | - | PT1000 | - | PT1000 |
| Sensor Accuracy ℃ | - | ±0.2 | - | ±0.2 |
| Temperature Accuracy ℃ | - | ±1 | - | ±1 |
| Temperature Setting Accuracy ℃ | - | 1 | - | 1 |
| Stirring Bar Range(mm) | 20~80 | 20~80 | 20~80 | 20~80 |
| Allowable Ambient Temperature℃ | 5~40 | 5~40 | 5~40 | 5~40 |
| Allowable Ambient Humidity % | 80 | 80 | 80 | 80 |
| Instrument Size(mm) | 165x280x105 | 165x280x105 | 165x280x105 | 165x280x105 |
| Packing Size(mm) | 425x390x200 | 425x390x200 | 425x390x200 | 425x390x200 |
| NW(kg) | 4 | 4 | 4 | 4 |
| GW(kg) | 5 | 5.2 | 5 | 5.2 |
